Anti-PICALM Picoband™ Antibody

Product Name

Anti-PICALM Picoband™ Antibody

View all PICALM Antibodies

SKU/Catalog Number

A02053-1

Size

100 μg/vial

Form

Lyophilized

Description

Boster Bio Anti-PICALM Picoband™ Antibody catalog # A02053-1. Tested in ELISA, Flow Cytometry, IF, IHC, ICC, WB applications. This antibody reacts with Human, Mouse, Rat.

Storage & Handling

Store at -20˚C for one year from date of receipt. After reconstitution, at 4˚C for one month. It can also be aliquotted and stored frozen at -20˚C for six months. Avoid repeated freeze-thaw cycles.

Cite This Product

Anti-PICALM Picoband™ Antibody (Boster Biological Technology, Pleasanton CA, USA, Catalog # A02053-1)

Host

Rabbit

Contents

Each vial contains 4mg Trehalose, 0.9mg NaCl, 0.2mg Na₂HPO₄, 0.05mg NaN₃.

Clonality

Polyclonal

Isotype

Rabbit IgG

Immunogen

E.coli-derived human PICALM recombinant protein (Position: M1-M652).

*Blocking peptide can be purchased. Costs vary based on immunogen length. Contact us for pricing.

Cross-reactivity

No cross-reactivity with other proteins.

Reactive Species

A02053-1 is reactive to PICALM in Human, Mouse, Rat

Applications

A02053-1 is guaranteed for ELISA, Flow Cytometry, IF, IHC, ICC, WB Boster Guarantee

Observed Molecular Weight

71 kDa

Calculated molecular weight

37492 MW

Background of PICALM

Phosphatidylinositol binding clathrin assembly protein, also known as PICALM, is a protein which in humans is encoded by the PICALM gene. It is mapped to 11q14.2. This gene encodes a clathrin assembly protein, which recruits clathrin and adaptor protein complex 2 (AP2) to cell membranes at sites of coated-pit formation and clathrin-vesicle assembly. The protein may be required to determine the amount of membrane to be recycled, possibly by regulating the size of the clathrin cage. The protein is involved in AP2-dependent clathrin-mediated endocytosis at the neuromuscular junction. A chromosomal translocation t (10;11) (p13;q14) leading to the fusion of this gene and the MLLT10 gene is found in acute lymphoblastic leukemia, acute myeloid leukemia and malignant lymphomas. The polymorphisms of this gene are associated with the risk of Alzheimer disease. Multiple alternatively spliced transcript variants encoding different isoforms have been found for this gene.

Antibody Validation

Boster validates all antibodies on WB, IHC, ICC, Immunofluorescence, and ELISA with known positive control and negative samples to ensure specificity and high affinity, including thorough antibody incubations.

View more details

Reconstitution

Add 0.2ml of distilled water will yield a concentration of 500ug/ml.

Assay Dilutions Recommendation

The recommendations below provide a starting point for assay optimization. The actual working concentration varies and should be decided by the user.

Western blot, 0.25-0.5μg/ml, Human, Mouse, Rat
Immunohistochemistry (Paraffin-embedded Section), 0.5-1μg/ml, Human, Mouse, Rat
Immunocytochemistry/Immunofluorescence, 2μg/ml, Human
Flow Cytometry (Fixed), 1-3μg/1x10⁶ cells, Human
Direct ELISA, 0.1-0.5μg/ml, Human

Validation Images & Assay Conditions

Click image to see more details

Figure 1. Western blot analysis of PICALM using anti-PICALM antibody (A02053-1).
Electrophoresis was performed on a 5-20% SDS-PAGE gel at 70V (Stacking gel) / 90V (Resolving gel) for 2-3 hours. The sample well of each lane was loaded with 50ug of sample under reducing conditions.
Lane 1: human HepG2 whole cell lysates,
Lane 2: rat lung tissue lysates,
Lane 3: mouse lung tissue lysates.
After Electrophoresis, proteins were transferred to a Nitrocellulose membrane at 150mA for 50-90 minutes. Blocked the membrane with 5% Non-fat Milk/ TBS for 1.5 hour at RT. The membrane was incubated with rabbit anti-PICALM antigen affinity purified polyclonal antibody (Catalog # A02053-1) at 0.5 μg/mL overnight at 4°C, then washed with TBS-0.1%Tween 3 times with 5 minutes each and probed with a goat anti-rabbit IgG-HRP secondary antibody at a dilution of 1:5000 for 1.5 hour at RT. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1002) with Tanon 5200 system. A specific band was detected for PICALM at approximately 71KD. The expected band size for PICALM is at 71KD.

Click image to see more details

Figure 2. IHC analysis of PICALM using anti-PICALM antibody (A02053-1).
PICALM was detected in paraffin-embedded section of human Ovarian cancer tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 1μg/ml rabbit anti-PICALM Antibody (A02053-1) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.

Click image to see more details

Figure 3. IF analysis of PICALM using anti-PICALM antibody (A02053-1).
PICALM was detected in immunocytochemical section of A431 cells. Enzyme antigen retrieval was performed using IHC enzyme antigen retrieval reagent (AR0022) for 15 mins. The cells were blocked with 10% goat serum. And then incubated with 2μg/mL rabbit anti-PICALM Antibody (A02053-1) overnight at 4°C. DyLight®488 conjugated Goat Anti-Rabbit IgG (BA1127) was used as secondary antibody at 1:100 dilution and incubated for 30 minutes at 37°C. The section was counterstained with DAPI. Visualize using a fluorescence microscope and filter sets appropriate for the label used.

Click image to see more details

Figure 4. Flow Cytometry analysis of A431 cells using anti-PICALM antibody (A02053-1).
Overlay histogram showing A431 cells stained with A02053-1 (Blue line).The cells were blocked with 10% normal goat serum. And then incubated with rabbit anti-PICALM Antibody (A02053-1, 1μg/1x10⁶ cells) for 30 min at 20°C. DyLight®488 conjugated goat anti-rabbit IgG (BA1127, 5-10μg/1x10⁶ cells) was used as secondary antibody for 30 minutes at 20°C. Isotype control antibody (Green line) was rabbit IgG (1μg/1x10⁶) used under the same conditions. Unlabelled sample (Red line) was also used as a control.

Gene/Protein Information For PICALM (Source: Uniprot.org, NCBI)

Alternative Names

CALMclathrin assembly lymphoid-myeloid leukemia; Clathrin assembly lymphoid myeloid leukemia protein; CLTHphosphatidylinositol-binding clathrin assembly protein; LAP; phosphatidylinositol binding clathrin assembly protein PICALM CALM, CLTH, LAP phosphatidylinositol binding clathrin assembly protein phosphatidylinositol-binding clathrin assembly protein|clathrin assembly lymphoid myeloid leukemia protein

For more info on PICALM, check out the PICALM Infographic

We have 30,000+ of these available, one for each gene! Check them out.

In this infographic, you will see the following information for PICALM: database IDs, superfamily, protein function, synonyms, molecular weight, chromosomal locations, tissues of expression, subcellular locations, post-translational modifications, and related diseases, research areas & pathways. If you want to see more information included, or would like to contribute to it and be acknowledged, please contact [email protected].

Take me to the PICALM Infographic
