Product Info Summary
| SKU: | A01246-2 |
|---|---|
| Size: | 100 μg/vial |
| Reactive Species: | Human |
| Host: | Rabbit |
| Application: | ELISA, Flow Cytometry, IF, IHC, ICC, WB |
Customers Who Bought This Also Bought
Product info
Product Name
Anti-Occludin/OCLN Antibody Picoband®
SKU/Catalog Number
A01246-2
Size
100 μg/vial
Form
Lyophilized
Description
Boster Bio Anti-Occludin/OCLN Antibody Picoband® catalog # A01246-2. Tested in ELISA, Flow Cytometry, IF, IHC, ICC, WB applications. This antibody reacts with Human. The brand Picoband indicates this is a premium antibody that guarantees superior quality, high affinity, and strong signals with minimal background in Western blot applications. Only our best-performing antibodies are designated as Picoband, ensuring unmatched performance.
Storage & Handling
Store at -20˚C for one year from date of receipt. After reconstitution, at 4˚C for one month. It can also be aliquotted and stored frozen at -20˚C for six months. Avoid repeated freeze-thaw cycles.
Cite This Product
Anti-Occludin/OCLN Antibody Picoband® (Boster Biological Technology, Pleasanton CA, USA, Catalog # A01246-2)
Host
Rabbit
Contents
Each vial contains 4mg Trehalose, 0.9mg NaCl, 0.2mg Na2HPO4, 0.01mg NaN3.
Clonality
Polyclonal
Isotype
Rabbit IgG
Immunogen
E.coli-derived human Occludin/OCLN recombinant protein (Position: H54-K270).
*Blocking peptide can be purchased. Costs vary based on immunogen length. Contact us for pricing.
Cross-reactivity
No cross-reactivity with other proteins.
Reactive Species
A01246-2 is reactive to OCLN in Human
Reconstitution
Add 0.2ml of distilled water will yield a concentration of 500ug/ml.
Observed Molecular Weight
65 kDa
Calculated molecular weight
59kDa
Background of Occludin
Occludin is an integral membrane protein that is located at tight junctions. It is a member of a family of proteins containing the highly conserved Marvel domain, which contains 4 transmembrane-helix regions. This gene is mapped to 5q13.2. Occludin regulates TGF-beta receptor type I localization for efficient TGF-beta-dependent dissolution of tight junctions during epithelial-mesenchymal transitions. Human Occludin is an essential hepatitis C virus (HCV) cell entry factor that is able to render murine cells infectable with HCV glycoproteins. It has been found that occludin is involved in cell migration and functions to recruit active PI3 kinase to the leading edge, resulting in RAC1 activation and formation of lamellipodia.
Antibody Validation
Boster validates all antibodies on WB, IHC, ICC, Immunofluorescence, and ELISA with known positive control and negative samples to ensure specificity and high affinity, including thorough antibody incubations.
Application & Images
Applications
A01246-2 is guaranteed for ELISA, Flow Cytometry, IF, IHC, ICC, WB Boster Guarantee
Assay Dilutions Recommendation
The recommendations below provide a starting point for assay optimization. The actual working concentration varies and should be decided by the user.
Western blot, 0.25-0.5μg/ml, Human
Immunohistochemistry (Paraffin-embedded Section), 2-5μg/ml, Human
Immunocytochemistry/Immunofluorescence, 5μg/ml, Human
Flow Cytometry (Fixed), 1-3μg/1x106 cells, Human
ELISA, 0.1-0.5μg/ml, -
Positive Control
WB: human HepG2 whole cell, human HEK293 whole cell
IHC: human mammary cancer tissue
ICC/IF: A431 cell
IP: HepG2 cell
FCM: U20S cell
Validation Images & Assay Conditions
Click image to see more details
Figure 1. Western blot analysis of Occludin/OCLN using anti-Occludin/OCLN antibody (A01246-2).
Electrophoresis was performed on a 5-20% SDS-PAGE gel at 70V (Stacking gel) / 90V (Resolving gel) for 2-3 hours. The sample well of each lane was loaded with 50ug of sample under reducing conditions.
Lane 1: human HepG2 whole cell lysates,
Lane 2: human HEK293 whole cell lysates.
After Electrophoresis, proteins were transferred to a Nitrocellulose membrane at 150mA for 50-90 minutes. Blocked the membrane with 5% Non-fat Milk/ TBS for 1.5 hour at RT. The membrane was incubated with rabbit anti-Occludin/OCLN antigen affinity purified polyclonal antibody (Catalog # A01246-2) at 0.5 μg/mL overnight at 4°C, then washed with TBS-0.1%Tween 3 times with 5 minutes each and probed with a goat anti-rabbit IgG-HRP secondary antibody at a dilution of 1:10000 for 1.5 hour at RT. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1002) with Tanon 5200 system. A specific band was detected for Occludin/OCLN at approximately 65KD. The expected band size for Occludin/OCLN is at 59KD.
Click image to see more details
Figure 2. IHC analysis of Occludin/OCLN using anti Occludin/OCLN antibody (A01246-2).
Occludin/OCLN was detected in paraffin-embedded section of human mammary cancer tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2μg/ml rabbit anti-Occludin/OCLN Antibody (A01246-2) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
Click image to see more details
Figure 3. IF analysis of Occludin/OCLN using anti-Occludin/OCLN antibody (A01246-2).
Occludin/OCLN was detected in immunocytochemical section of A431 cells. Enzyme antigen retrieval was performed using IHC enzyme antigen retrieval reagent (AR0022) for 15 mins. The cells were blocked with 10% goat serum. And then incubated with 5μg/mL rabbit anti-Occludin/OCLN Antibody (A01246-2) overnight at 4°C. DyLight®488 Conjugated Goat Anti-Rabbit IgG (BA1127) was used as secondary antibody at 1:100 dilution and incubated for 30 minutes at 37°C. The section was counterstained with DAPI. Visualize using a fluorescence microscope and filter sets appropriate for the label used.
Click image to see more details
Figure 4. Flow Cytometry analysis of U20S cells using anti-Occludin/OCLN antibody (A01246-2).
Overlay histogram showing U20S cells stained with A01246-2 (Blue line). The cells were fixed with 4% paraformaldehyde and blocked with 10% normal goat serum. And then incubated with rabbit anti-Occludin/OCLN Antibody (A01246-2,1μg/1x106 cells) for 30 min at 20°C. DyLight®488 conjugated goat anti-rabbit IgG (BA1127, 5-10μg/1x106 cells) was used as secondary antibody for 30 minutes at 20°C. Isotype control antibody (Green line) was rabbit IgG (1μg/1x106) used under the same conditions. Unlabelled sample without incubation with primary antibody and secondary antibody (Red line) was used as a blank control.
Protein Target Info & Infographic
Gene/Protein Information For OCLN (Source: Uniprot.org, NCBI)
Gene Name
OCLN
Full Name
Occludin
Weight
59kDa
Superfamily
ELL/occludin family
Alternative Names
Cyclin-dependent kinase inhibitor 1C; Cyclin-dependent kinase inhibitor p57; p57Kip2; CDKN1C; KIP2 Ocln|AI503564, O, Ocl|occludin|occludin
*If product is indicated to react with multiple species, protein info is based on the gene entry specified above in "Species".For more info on OCLN, check out the OCLN Infographic
We have 30,000+ of these available, one for each gene! Check them out.
In this infographic, you will see the following information for OCLN: database IDs, superfamily, protein function, synonyms, molecular weight, chromosomal locations, tissues of expression, subcellular locations, post-translational modifications, and related diseases, research areas & pathways. If you want to see more information included, or would like to contribute to it and be acknowledged, please contact [email protected].
Specific Publications For Anti-Occludin/OCLN Antibody Picoband® (A01246-2)
Hello CJ!
A01246-2 has been cited in 2 publications:
*The publications in this section are manually curated by our staff scientists. They may differ from Bioz's machine gathered results. Both are accurate. If you find a publication citing this product but is missing from this list, please let us know we will issue you a thank-you coupon.
Qing-qing Zhang,Ye Yang,Rong-rong Ren,Qing-qing Chen,Jing-jing Wu,Yu-yu Zheng,Xiao-hui Hou,Yu-feng Zhang,Ming-song Xue,Deng-ke Yin,Self-assembled aggregations in Coptis chinensis decoction dynamically regulate intestinal tissue permeability through peyer‘s patch-associated immunity,Chinese Herbal Medicines,2021,,ISSN 1674-6384,https://doi.org/10.1016/j.chmed.2021.06.004.
Species: Rat
A01246-2 usage in article: APP:WB, SAMPLE:JEJUNAL TISSUE, DILUTION:NA
Xiaozhu Tian,Rong Li,Yiming Jiang,Fei Zhao,Zhengsheng Yu,Yiqing Wang,Zixing Dong,Pu Liu,Xiangkai Li,Bifidobacterium breve ATCC15700 pretreatment prevents alcoholic liver disease through modulating gut microbiota in mice exposed to chronic alcohol intake,J
Species: Mouse
A01246-2 usage in article: APP:WB, SAMPLE:LIVER TISSUE AND ILEUM, DILUTION:NA
