Anti-Myelin oligodendrocyte glycoprotein/MOG Antibody Picoband®

Figure 1. Western blot analysis of Myelin oligodendrocyte glycoprotein using anti-Myelin oligodendrocyte glycoprotein antibody (A03294).
Electrophoresis was performed on a 5-20% SDS-PAGE gel at 70V (Stacking gel) / 90V (Resolving gel) for 2-3 hours. The sample well of each lane was loaded with 50ug of sample under reducing conditions.
Lane 1: rat brain tissue lysates,
Lane 2: mouse brain tissue lysates,
After Electrophoresis, proteins were transferred to a Nitrocellulose membrane at 150mA for 50-90 minutes. Blocked the membrane with 5% Non-fat Milk/ TBS for 1.5 hour at RT. The membrane was incubated with rabbit anti-Myelin oligodendrocyte glycoprotein antigen affinity purified polyclonal antibody (Catalog # A03294) at 0.5 μg/mL overnight at 4°C, then washed with TBS-0.1%Tween 3 times with 5 minutes each and probed with a goat anti-rabbit IgG-HRP secondary antibody at a dilution of 1:10000 for 1.5 hour at RT. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1002) with Tanon 5200 system. A specific band was detected for Myelin oligodendrocyte glycoprotein at approximately 26KD. The expected band size for Myelin oligodendrocyte glycoprotein is at 28KD.

Figure 2. IHC analysis of Myelin oligodendrocyte glycoprotein using anti-Myelin oligodendrocyte glycoprotein antibody (A03294).
Myelin oligodendrocyte glycoprotein was detected in paraffin-embedded section of human glioma tissues. Heat mediated antigen retrieval was performed in citrate buffer (pH6, epitope retrieval solution) for 20 mins. The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 1μg/ml rabbit anti-Myelin oligodendrocyte glycoprotein Antibody (A03294) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC)(Catalog # SA1022) with DAB as the chromogen.

Figure 3. IHC analysis of Myelin oligodendrocyte glycoprotein using anti-Myelin oligodendrocyte glycoprotein antibody (A03294).
Myelin oligodendrocyte glycoprotein was detected in paraffin-embedded section of mouse brain tissues. Heat mediated antigen retrieval was performed in citrate buffer (pH6, epitope retrieval solution) for 20 mins. The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 1μg/ml rabbit anti-Myelin oligodendrocyte glycoprotein Antibody (A03294) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC)(Catalog # SA1022) with DAB as the chromogen.

Figure 4. IHC analysis of Myelin oligodendrocyte glycoprotein using anti-Myelin oligodendrocyte glycoprotein antibody (A03294).
Myelin oligodendrocyte glycoprotein was detected in paraffin-embedded section of rat brain tissues. Heat mediated antigen retrieval was performed in citrate buffer (pH6, epitope retrieval solution) for 20 mins. The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 1μg/ml rabbit anti-Myelin oligodendrocyte glycoprotein Antibody (A03294) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC)(Catalog # SA1022) with DAB as the chromogen.

Figure 5. IHC analysis of Myelin oligodendrocyte glycoprotein using anti-Myelin oligodendrocyte glycoprotein antibody (A03294).
Myelin oligodendrocyte glycoprotein was detected in paraffin-embedded section of rat brain tissues. Heat mediated antigen retrieval was performed in citrate buffer (pH6, epitope retrieval solution) for 20 mins. The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 1μg/ml rabbit anti-Myelin oligodendrocyte glycoprotein Antibody (A03294) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC)(Catalog # SA1022) with DAB as the chromogen.

Figure 6. Flow Cytometry analysis of U251 cells using anti-Myelin oligodendrocyte glycoprotein antibody (A03294).
Overlay histogram showing U251 cells stained with A03294 (Blue line). To facilitate intracellular staining, cells were fixed with 4% paraformaldehyde and permeabilized with permeabilization buffer. The cells were blocked with 10% normal goat serum. And then incubated with rabbit anti-Myelin oligodendrocyte glycoprotein Antibody (A03294,1μg/1x10⁶ cells) for 30 min at 20°C. DyLight®488 conjugated goat anti-rabbit IgG (BA1127, 5-10μg/1x10⁶ cells) was used as secondary antibody for 30 minutes at 20°C. Isotype control antibody (Green line) was rabbit IgG (1μg/1x10⁶) used under the same conditions. Unlabelled sample (Red line) was also used as a control.
