Product Info Summary
| SKU: | A01725-1 |
|---|---|
| Size: | 100 μg/vial |
| Reactive Species: | Human, Mouse, Rat |
| Host: | Rabbit |
| Application: | ELISA, WB |
Customers Who Bought This Also Bought
Product info
Product Name
Anti-MEK4/MAP2K4 Antibody Picoband®
SKU/Catalog Number
A01725-1
Size
100 μg/vial
Form
Lyophilized
Description
Boster Bio Anti-MEK4/MAP2K4 Antibody Picoband® catalog # A01725-1. Tested in ELISA, WB applications. This antibody reacts with Human, Mouse, Rat. The brand Picoband indicates this is a premium antibody that guarantees superior quality, high affinity, and strong signals with minimal background in Western blot applications. Only our best-performing antibodies are designated as Picoband, ensuring unmatched performance.
Storage & Handling
Store at -20˚C for one year from date of receipt. After reconstitution, at 4˚C for one month. It can also be aliquotted and stored frozen at -20˚C for six months. Avoid repeated freeze-thaw cycles.
Cite This Product
Anti-MEK4/MAP2K4 Antibody Picoband® (Boster Biological Technology, Pleasanton CA, USA, Catalog # A01725-1)
Host
Rabbit
Contents
Each vial contains 4mg Trehalose, 0.9mg NaCl, 0.2mg Na2HPO4, 0.05mg NaN3.
Clonality
Polyclonal
Isotype
Rabbit IgG
Immunogen
E.coli-derived human MEK4/MAP2K4 recombinant protein (Position: E92-A378).
*Blocking peptide can be purchased. Costs vary based on immunogen length. Contact us for pricing.
Cross-reactivity
No cross-reactivity with other proteins.
Reactive Species
A01725-1 is reactive to MAP2K4 in Human, Mouse, Rat
Reconstitution
Add 0.2ml of distilled water will yield a concentration of 500ug/ml.
Observed Molecular Weight
44 kDa
Calculated molecular weight
57954 MW
Background of MKK4/MEK4
Dual specificity mitogen-activated protein kinase kinase 4 is an enzyme that in humans is encoded by the MAP2K4 gene. It is mapped to 10q23.31. This gene encodes a member of the mitogen-activated protein kinase (MAPK) family. Members of this family act as an integration point for multiple biochemical signals and are involved in a wide variety of cellular processes such as proliferation, differentiation, transcription regulation, and development. They form a three-tiered signaling module composed of MAPKKKs, MAPKKs, and MAPKs. This protein is phosphorylated at serine and threonine residues by MAPKKKs and subsequently phosphorylates downstream MAPK targets at threonine and tyrosine residues. A similar protein in mouse has been reported to play a role in liver organogenesis. A pseudogene of this gene is located on the long arm of chromosome X. Alternative splicing results in multiple transcript variants.
Antibody Validation
Boster validates all antibodies on WB, IHC, ICC, Immunofluorescence, and ELISA with known positive control and negative samples to ensure specificity and high affinity, including thorough antibody incubations.
Application & Images
Applications
A01725-1 is guaranteed for ELISA, WB Boster Guarantee
Assay Dilutions Recommendation
The recommendations below provide a starting point for assay optimization. The actual working concentration varies and should be decided by the user.
Western blot, 0.1-0.5μg/ml
ELISA, 0.1-0.5μg/ml
Positive Control
WB: human Hela whole cell, human placenta tissue, human MCF-7 whole cell, human A549 whole cell, human 22RV1 whole cell, rat brain tissue, rat kidney tissue, rat skeletal muscle tissue, mouse brain tissue, mouse kidney tissue, mouse lung tissue
Validation Images & Assay Conditions
Click image to see more details
Figure 1. Western blot analysis of MAP2K4 using anti-MAP2K4 antibody (A01725-1).
Electrophoresis was performed on a 5-20% SDS-PAGE gel at 70V (Stacking gel) / 90V (Resolving gel) for 2-3 hours. The sample well of each lane was loaded with 50ug of sample under reducing conditions.
Lane 1: human Hela whole cell lysates,
Lane 2: human placenta tissue lysates,
Lane 3: human MCF-7 whole cell lysates,
Lane 4: human A549 whole cell lysates,
Lane 5: human 22RV1 whole cell lysates.
After Electrophoresis, proteins were transferred to a Nitrocellulose membrane at 150mA for 50-90 minutes. Blocked the membrane with 5% Non-fat Milk/ TBS for 1.5 hour at RT. The membrane was incubated with rabbit anti-MAP2K4 antigen affinity purified polyclonal antibody (Catalog # A01725-1) at 0.5 μg/mL overnight at 4°C, then washed with TBS-0.1%Tween 3 times with 5 minutes each and probed with a goat anti-rabbit IgG-HRP secondary antibody at a dilution of 1:10000 for 1.5 hour at RT. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1002) with Tanon 5200 system. A specific band was detected for MAP2K4 at approximately 44KD. The expected band size for MAP2K4 is at 44KD.
Click image to see more details
Figure 2. Western blot analysis of MAP2K4 using anti-MAP2K4 antibody (A01725-1).
Electrophoresis was performed on a 5-20% SDS-PAGE gel at 70V (Stacking gel) / 90V (Resolving gel) for 2-3 hours. The sample well of each lane was loaded with 50ug of sample under reducing conditions.
Lane 1: rat brain tissue lysates,
Lane 2: rat kidney tissue lysates,
Lane 3: rat skeletal muscle tissue lysates,
Lane 4: mouse brain tissue lysates,
Lane 5: mouse kidney tissue lysates,
Lane 6: mouse lung tissue lysates.
After Electrophoresis, proteins were transferred to a Nitrocellulose membrane at 150mA for 50-90 minutes. Blocked the membrane with 5% Non-fat Milk/ TBS for 1.5 hour at RT. The membrane was incubated with rabbit anti-MAP2K4 antigen affinity purified polyclonal antibody (Catalog # A01725-1) at 0.5 μg/mL overnight at 4°C, then washed with TBS-0.1%Tween 3 times with 5 minutes each and probed with a goat anti-rabbit IgG-HRP secondary antibody at a dilution of 1:10000 for 1.5 hour at RT. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1002) with Tanon 5200 system. A specific band was detected for MAP2K4 at approximately 44KD. The expected band size for MAP2K4 is at 44KD.
Protein Target Info & Infographic
Gene/Protein Information For MAP2K4 (Source: Uniprot.org, NCBI)
Gene Name
MAP2K4
Full Name
Dual specificity mitogen-activated protein kinase kinase 4
Weight
57954 MW
Superfamily
protein kinase superfamily
Alternative Names
Dual specificity mitogen-activated protein kinase kinase 4; MAP kinase kinase 4; MAPKK 4; JNK-activating kinase 1; MAPK/ERK kinase 4; MEK 4; SAPK/ERK kinase 1; SEK1; Stress-activated protein kinase kinase 1; SAPK kinase 1; SAPKK-1; SAPKK1; c-Jun N-terminal kinase kinase 1; JNKK; MAP2K4; JNKK1; MEK4; MKK4; PRKMK4; SEK1; SERK1; SKK1 MAP2K4 JNKK, JNKK1, MAPKK4, MEK4, MKK4, PRKMK4, SAPKK-1, SAPKK1, SEK1, SERK1, SKK1 mitogen-activated protein kinase kinase 4 dual specificity mitogen-activated protein kinase kinase 4|JNK-activated kinase 1|JNK-activating kinase 1|MAP kinase kinase 4|MAPK/ERK kinase 4|MAPKK 4|MEK 4|SAPK/ERK kinase 1|c-Jun N-terminal kinase kinase 1|stress-activated protein kinase kinase 1
*If product is indicated to react with multiple species, protein info is based on the gene entry specified above in "Species".For more info on MAP2K4, check out the MAP2K4 Infographic
We have 30,000+ of these available, one for each gene! Check them out.
In this infographic, you will see the following information for MAP2K4: database IDs, superfamily, protein function, synonyms, molecular weight, chromosomal locations, tissues of expression, subcellular locations, post-translational modifications, and related diseases, research areas & pathways. If you want to see more information included, or would like to contribute to it and be acknowledged, please contact [email protected].
