Product Info Summary
| SKU: | A01326-1 |
|---|---|
| Size: | 100 μg/vial |
| Reactive Species: | Human, Monkey |
| Host: | Rabbit |
| Application: | ELISA, Flow Cytometry, IF, IHC, ICC, WB |
Customers Who Bought This Also Bought
Product info
Product Name
Anti-WFS1 Antibody Picoband®
SKU/Catalog Number
A01326-1
Size
100 μg/vial
Form
Lyophilized
Description
Boster Bio Anti-WFS1 Antibody Picoband® catalog # A01326-1. Tested in ELISA, Flow Cytometry, IF, IHC, ICC, WB applications. This antibody reacts with Human, Monkey. The brand Picoband indicates this is a premium antibody that guarantees superior quality, high affinity, and strong signals with minimal background in Western blot applications. Only our best-performing antibodies are designated as Picoband, ensuring unmatched performance.
Storage & Handling
Store at -20˚C for one year from date of receipt. After reconstitution, at 4˚C for one month. It can also be aliquotted and stored frozen at -20˚C for six months. Avoid repeated freeze-thaw cycles.
Cite This Product
Anti-WFS1 Antibody Picoband® (Boster Biological Technology, Pleasanton CA, USA, Catalog # A01326-1)
Host
Rabbit
Contents
Each vial contains 4mg Trehalose, 0.9mg NaCl and 0.2mg Na2HPO4.
Clonality
Polyclonal
Isotype
Rabbit IgG
Immunogen
E.coli-derived human WFS1 recombinant protein (Position: A61-H313).
*Blocking peptide can be purchased. Costs vary based on immunogen length. Contact us for pricing.
Cross-reactivity
No cross-reactivity with other proteins.
Reactive Species
A01326-1 is reactive to WFS1 in Human, Monkey
Reconstitution
Add 0.2ml of distilled water will yield a concentration of 500ug/ml.
Observed Molecular Weight
100 kDa
Calculated molecular weight
60066 MW
Background of WFS1
Wolframin is a protein that in humans is encoded by the WFS1 gene. This gene encodes a transmembrane protein, which is located primarily in the endoplasmic reticulum and ubiquitously expressed with highest levels in brain, pancreas, heart, and insulinoma beta-cell lines. Mutations in this gene are associated with Wolfram syndrome, also called DIDMOAD (Diabetes Insipidus, Diabetes Mellitus, Optic Atrophy, and Deafness), an autosomal recessive disorder. The disease affects the brain and central nervous system. Mutations in this gene can also cause autosomal dominant deafness 6 (DFNA6), also known as DFNA14 or DFNA38. Alternatively spliced transcript variants have been found for this gene.
Antibody Validation
Boster validates all antibodies on WB, IHC, ICC, Immunofluorescence, and ELISA with known positive control and negative samples to ensure specificity and high affinity, including thorough antibody incubations.
Application & Images
Applications
A01326-1 is guaranteed for ELISA, Flow Cytometry, IF, IHC, ICC, WB Boster Guarantee
Assay Dilutions Recommendation
The recommendations below provide a starting point for assay optimization. The actual working concentration varies and should be decided by the user.
Western blot, 0.25-0.5μg/ml, Human, Monkey
Immunohistochemistry (Paraffin-embedded Section), 2-5μg/ml, Human
Immunocytochemistry/Immunofluorescence, 5μg/ml, Human
Flow Cytometry (Fixed), 1-3μg/1x106 cells, Human
ELISA, 0.1-0.5μg/ml, -
Positive Control
WB: human placenta tissue, human T-47D whole cell, monkey lung tissue
IHC: human lung cancer tissue
ICC/IF: HepG2 cell
FCM: U20S cell
Validation Images & Assay Conditions
Click image to see more details
Figure 1. Western blot analysis of WFS1 using anti-WFS1 antibody (A01326-1).
Electrophoresis was performed on a 5-20% SDS-PAGE gel at 70V (Stacking gel) / 90V (Resolving gel) for 2-3 hours. The sample well of each lane was loaded with 30ug of sample under reducing conditions.
Lane 1: human placenta tissue lysates,
Lane 2: human T-47D whole cell lysates,
Lane 3: monkey lung tissue lysates.
After Electrophoresis, proteins were transferred to a Nitrocellulose membrane at 150mA for 50-90 minutes. Blocked the membrane with 5% Non-fat Milk/ TBS for 1.5 hour at RT. The membrane was incubated with rabbit anti-WFS1 antigen affinity purified polyclonal antibody (Catalog # A01326-1) at 0.5 μg/mL overnight at 4°C, then washed with TBS-0.1%Tween 3 times with 5 minutes each and probed with a goat anti-rabbit IgG-HRP secondary antibody at a dilution of 1:5000 for 1.5 hour at RT. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1002) with Tanon 5200 system. A specific band was detected for WFS1 at approximately 100KD. The expected band size for WFS1 is at 100KD.
Click image to see more details
Figure 2. IHC analysis of WFS1 using anti-WFS1 antibody (A01326-1).
WFS1 was detected in paraffin-embedded section of human lung cancer tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2μg/ml rabbit anti-WFS1 Antibody (A01326-1) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
Click image to see more details
Figure 3. IF analysis of WFS1 using anti-WFS1 antibody (A01326-1).
WFS1 was detected in immunocytochemical section of HepG2 cells. Enzyme antigen retrieval was performed using IHC enzyme antigen retrieval reagent (AR0022) for 15 mins. The cells were blocked with 10% goat serum. And then incubated with 5μg/mL rabbit anti-WFS1 Antibody (A01326-1) overnight at 4°C. DyLight®488 Conjugated Goat Anti-Rabbit IgG (BA1127) was used as secondary antibody at 1:100 dilution and incubated for 30 minutes at 37°C. The section was counterstained with DAPI. Visualize using a fluorescence microscope and filter sets appropriate for the label used.
Click image to see more details
Figure 4. Flow Cytometry analysis of U20S cells using anti-WFS1 antibody (A01326-1).
Overlay histogram showing U20S cells stained with A01326-1 (Blue line). To facilitate intracellular staining, cells were fixed with 4% paraformaldehyde and permeabilized with permeabilization buffer. The cells were blocked with 10% normal goat serum. And then incubated with rabbit anti-WFS1 Antibody (A01326-1, 1μg/1x106 cells) for 30 min at 20°C. DyLight®488 conjugated goat anti-rabbit IgG (BA1127, 5-10μg/1x106 cells) was used as secondary antibody for 30 minutes at 20°C. Isotype control antibody (Green line) was rabbit IgG (1μg/1x106) used under the same conditions. Unlabelled sample without incubation with primary antibody and secondary antibody (Red line) was used as a blank control.
Protein Target Info & Infographic
Gene/Protein Information For WFS1 (Source: Uniprot.org, NCBI)
Gene Name
WFS1
Full Name
Wolframin
Weight
60066 MW
Alternative Names
Wee1-like protein kinase; WEE1hu; Wee1A kinase; WEE1 WFS1 CTRCT41, WFRS, WFS, WFSL wolframin ER transmembrane glycoprotein wolframin|Wolfram syndrome 1 (wolframin)
*If product is indicated to react with multiple species, protein info is based on the gene entry specified above in "Species".For more info on WFS1, check out the WFS1 Infographic
We have 30,000+ of these available, one for each gene! Check them out.
In this infographic, you will see the following information for WFS1: database IDs, superfamily, protein function, synonyms, molecular weight, chromosomal locations, tissues of expression, subcellular locations, post-translational modifications, and related diseases, research areas & pathways. If you want to see more information included, or would like to contribute to it and be acknowledged, please contact [email protected].
Specific Publications For Anti-WFS1 Antibody Picoband® (A01326-1)
Hello CJ!
No publications found for A01326-1
*Do you have publications using this product? Share with us and receive a reward. Ask us for more details.
