Product Info Summary
| SKU: | M01930-1 |
|---|---|
| Size: | 100 μg/vial |
| Reactive Species: | Human, Mouse, Rat |
| Host: | Mouse |
| Application: | IHC, WB |
Customers Who Bought This Also Bought
Product info
Product Name
Anti-SMC3 Antibody Picoband® (monoclonal, 4C12)
SKU/Catalog Number
M01930-1
Size
100 μg/vial
Form
Lyophilized
Description
Boster Bio Anti-SMC3 Antibody Picoband® (monoclonal, 4C12) catalog # M01930-1. Tested in IHC, WB applications. This antibody reacts with Human, Mouse, Rat. The brand Picoband indicates this is a premium antibody that guarantees superior quality, high affinity, and strong signals with minimal background in Western blot applications. Only our best-performing antibodies are designated as Picoband, ensuring unmatched performance.
Storage & Handling
Store at -20˚C for one year from date of receipt. After reconstitution, at 4˚C for one month. It can also be aliquotted and stored frozen at -20˚C for six months. Avoid repeated freeze-thaw cycles.
Cite This Product
Anti-SMC3 Antibody Picoband® (monoclonal, 4C12) (Boster Biological Technology, Pleasanton CA, USA, Catalog # M01930-1)
Host
Mouse
Contents
Each vial contains 4mg Trehalose, 0.9mg NaCl, 0.2mg Na2HPO4, 0.05mg NaN3.
Clonality
Monoclonal
Clone Number
4C12
Isotype
Mouse IgG1
Immunogen
A synthetic peptide corresponding to a sequence at the C-terminus of human SMC3 , identical to the related mouse sequence.
*Blocking peptide can be purchased. Costs vary based on immunogen length. Contact us for pricing.
Cross-reactivity
No cross-reactivity with other proteins.
Reactive Species
M01930-1 is reactive to SMC3 in Human, Mouse, Rat
Reconstitution
Add 0.2ml of distilled water will yield a concentration of 500ug/ml.
Observed Molecular Weight
142 kDa
Calculated molecular weight
25035 MW
Background of SMC3
Structural maintenance of chromosomes 3, also known as SMC3, is a human gene. This gene belongs to the SMC3 subfamily of SMC proteins. The encoded protein occurs in certain cell types as either an intracellular, nuclear protein or a secreted protein. The nuclear form, known as structural maintenance of chromosomes 3, is a component of the multimeric cohesin complex that holds together sister chromatids during mitosis, enabling proper chromosome segregation. Post-translational modification of the encoded protein by the addition of chondroitin sulfate chains gives rise to the secreted proteoglycan bamacan, an abundant basement membrane protein.
Antibody Validation
Boster validates all antibodies on WB, IHC, ICC, Immunofluorescence, and ELISA with known positive control and negative samples to ensure specificity and high affinity, including thorough antibody incubations.
Application & Images
Applications
M01930-1 is guaranteed for IHC, WB Boster Guarantee
Assay Dilutions Recommendation
The recommendations below provide a starting point for assay optimization. The actual working concentration varies and should be decided by the user.
Western blot, 0.1-0.5μg/ml
Immunohistochemistry (Paraffin-embedded Section), 0.5-1μg/ml
Positive Control
WB: human 293T whole cell, human Hela whole cell, human MCF-7 whole cell, human MDA-MB-453 whole cell, rat thymus tissue, rat liver tissue, mouse thymus tissue, mouse liver tissue
IHC: human lung cancer tissue, human intestinal cancer tissue
Validation Images & Assay Conditions
Click image to see more details
Figure 1. Western blot analysis of SMC3 using anti-SMC3 antibody (M01930-1).
Electrophoresis was performed on a 5-20% SDS-PAGE gel at 70V (Stacking gel) / 90V (Resolving gel) for 2-3 hours. The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: human 293T whole cell lysates,
Lane 2: human Hela whole cell lysates,
Lane 3: human MCF-7 whole cell lysates,
Lane 4: human MDA-MB-453 whole cell lysates,
Lane 5: rat thymus tissue lysates,
Lane 6: rat liver tissue lysates,
Lane 7: mouse thymus tissue lysates,
Lane 8: mouse liver tissue lysates.
After electrophoresis, proteins were transferred to a nitrocellulose membrane at 150 mA for 50-90 minutes. Blocked the membrane with 5% non-fat milk/TBS for 1.5 hour at RT. The membrane was incubated with mouse anti-SMC3 antigen affinity purified monoclonal antibody (Catalog # M01930-1) at 0.5 μg/mL overnight at 4°C, then washed with TBS-0.1%Tween 3 times with 5 minutes each and probed with a goat anti-mouse IgG-HRP secondary antibody at a dilution of 1:10000 for 1.5 hour at RT. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1001) with Tanon 5200 system. A specific band was detected for SMC3 at approximately 142 kDa. The expected band size for SMC3 is at 142 kDa.
Click image to see more details
Figure 2. IHC analysis of SMC3 using anti-SMC3 antibody (M01930-1).
SMC3 was detected in paraffin-embedded section of human lung cancer tissue. Heat mediated antigen retrieval was performed in citrate buffer (pH6, epitope retrieval solution) for 20 mins. The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2μg/ml mouse anti-SMC3 Antibody (M01930-1) overnight at 4°C. Biotinylated goat anti-mouse IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC)(Catalog # SA1021) with DAB as the chromogen.
Click image to see more details
Figure 3. IHC analysis of SMC3 using anti-SMC3 antibody (M01930-1).
SMC3 was detected in paraffin-embedded section of human intestinal cancer tissue. Heat mediated antigen retrieval was performed in citrate buffer (pH6, epitope retrieval solution) for 20 mins. The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2μg/ml mouse anti-SMC3 Antibody (M01930-1) overnight at 4°C. Biotinylated goat anti-mouse IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC)(Catalog # SA1021) with DAB as the chromogen.
Protein Target Info & Infographic
Gene/Protein Information For SMC3 (Source: Uniprot.org, NCBI)
Gene Name
SMC3
Full Name
Structural maintenance of chromosomes protein 3
Weight
25035 MW
Superfamily
SMC family
Alternative Names
Structural maintenance of chromosomes protein 3; SMC protein 3; SMC-3; Basement membrane-associated chondroitin proteoglycan; Bamacan; Chondroitin sulfate proteoglycan 6; Chromosome-associated polypeptide; hCAP; SMC3; BAM; BMH; CSPG6; SMC3L1 SMC3 BAM, BMH, CDLS3, CSPG6, HCAPL1, SMC3 structural maintenance of chromosomes 3 structural maintenance of chromosomes protein 3|SMC protein 3|basement membrane-associated chondroitin proteoglycan|chondroitin sulfate proteoglycan 6 (bamacan)|chromosome-associated polypeptide
*If product is indicated to react with multiple species, protein info is based on the gene entry specified above in "Species".For more info on SMC3, check out the SMC3 Infographic
We have 30,000+ of these available, one for each gene! Check them out.
In this infographic, you will see the following information for SMC3: database IDs, superfamily, protein function, synonyms, molecular weight, chromosomal locations, tissues of expression, subcellular locations, post-translational modifications, and related diseases, research areas & pathways. If you want to see more information included, or would like to contribute to it and be acknowledged, please contact [email protected].
