Product Info Summary
SKU: | A05430-2 |
---|---|
Size: | 100 μg/vial |
Reactive Species: | Human, Mouse, Rat |
Host: | Rabbit |
Application: | ELISA, Flow Cytometry, IF, IHC, ICC, WB |
Customers Who Bought This Also Bought
Product info
Product Name
Anti-SH3GL2 Antibody Picoband®
View all Endophilin A1/SH3GL2 Antibodies
SKU/Catalog Number
A05430-2
Size
100 μg/vial
Form
Lyophilized
Description
Boster Bio Anti-SH3GL2 Antibody Picoband® catalog # A05430-2. Tested in ELISA, Flow Cytometry, IF, IHC, ICC, WB applications. This antibody reacts with Human, Mouse, Rat. The brand Picoband indicates this is a premium antibody that guarantees superior quality, high affinity, and strong signals with minimal background in Western blot applications. Only our best-performing antibodies are designated as Picoband, ensuring unmatched performance.
Storage & Handling
At -20°C for one year from date of receipt. After reconstitution, at 4°C for one month. It can also be aliquotted and stored frozen at -20°C for six months. Avoid repeated freezing and thawing.
Cite This Product
Anti-SH3GL2 Antibody Picoband® (Boster Biological Technology, Pleasanton CA, USA, Catalog # A05430-2)
Host
Rabbit
Contents
Each vial contains 4 mg Trehalose, 0.9 mg NaCl, 0.2 mg Na2HPO4.
Clonality
Polyclonal
Isotype
Rabbit IgG
Immunogen
E.coli-derived human SH3GL2 recombinant protein (Position: R65-Q292).
*Blocking peptide can be purchased. Costs vary based on immunogen length. Contact us for pricing.
Cross-reactivity
No cross-reactivity with other proteins.
Reactive Species
A05430-2 is reactive to SH3GL2 in Human, Mouse, Rat
Reconstitution
Adding 0.2 ml of distilled water will yield a concentration of 500 μg/ml.
Observed Molecular Weight
41 kDa
Calculated molecular weight
39411 MW
Background of Endophilin A1/SH3GL2
Endophilin-A1 is a protein that in humans is encoded by the SH3GL2 gene. Endophilin proteins are part of a large family of Bin/Amphiphysin/Rvs (BAR) domain proteins that are involved in cell membrane remodeling. The endophilins are encoded by five genes, which produce endophilin A 1-3 and B 1-2. Endophilins are involved in many cellular mechanisms, such as synaptic vesicle recycling, receptor trafficking, and membrane remodeling processes. Research studies indicate that endophilin 1 (endophilin A1, SH3GL2) can induce different membrane shapes and participate in the morphogenesis of dendritic spines. Endophilin 1 is also involved in regulating blood brain barrier permeability via the EGFR-JNK pathway.
Antibody Validation
Boster validates all antibodies on WB, IHC, ICC, Immunofluorescence, and ELISA with known positive control and negative samples to ensure specificity and high affinity, including thorough antibody incubations.
Application & Images
Applications
A05430-2 is guaranteed for ELISA, Flow Cytometry, IF, IHC, ICC, WB Boster Guarantee
Assay Dilutions Recommendation
The recommendations below provide a starting point for assay optimization. The actual working concentration varies and should be decided by the user.
Western blot, 0.25-0.5 μg/ml, Mouse, Rat
Immunohistochemistry(Paraffin-embedded Section), 2-5 μg/ml, Human, Mouse, Rat
Immunocytochemistry/Immunofluorescence, 5 μg/ml, Human
Flow Cytometry (Fixed), 1-3 μg/1x106 cells, Human
ELISA, 0.1-0.5 μg/ml, -
Positive Control
WB: rat brain tissue, mouse brain tissue
IHC: human laryngeal squamous cell carcinoma tissue, human gastric cancer tissue, human hashimoto thyroiditis tissue, mouse brain tissue, rat brain tissue
ICC/IF: Hela cell
FCM: JK cell
Validation Images & Assay Conditions
Click image to see more details
Figure 1. Western blot analysis of SH3GL2 using anti-SH3GL2 antibody (A05430-2).
Electrophoresis was performed on a 5-20% SDS-PAGE gel at 70V (Stacking gel) / 90V (Resolving gel) for 2-3 hours. The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: rat brain tissue lysates,
Lane 2: mouse brain tissue lysates.
After electrophoresis, proteins were transferred to a nitrocellulose membrane at 150 mA for 50-90 minutes. Blocked the membrane with 5% non-fat milk/TBS for 1.5 hour at RT. The membrane was incubated with rabbit anti-SH3GL2 antigen affinity purified polyclonal antibody (Catalog # A05430-2) at 0.5 μg/mL overnight at 4°C, then washed with TBS-0.1%Tween 3 times with 5 minutes each and probed with a goat anti-rabbit IgG-HRP secondary antibody at a dilution of 1:5000 for 1.5 hour at RT. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1002) with Tanon 5200 system. A specific band was detected for SH3GL2 at approximately 41 kDa. The expected band size for SH3GL2 is at 41 kDa.
Click image to see more details
Figure 2. IHC analysis of SH3GL2 using anti-SH3GL2 antibody (A05430-2).
SH3GL2 was detected in a paraffin-embedded section of human laryngeal squamous cell carcinoma tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml rabbit anti-SH3GL2 Antibody (A05430-2) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
Click image to see more details
Figure 3. IHC analysis of SH3GL2 using anti-SH3GL2 antibody (A05430-2).
SH3GL2 was detected in a paraffin-embedded section of human gastric cancer tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml rabbit anti-SH3GL2 Antibody (A05430-2) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
Click image to see more details
Figure 4. IHC analysis of SH3GL2 using anti-SH3GL2 antibody (A05430-2).
SH3GL2 was detected in a paraffin-embedded section of human hashimoto thyroiditis tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml rabbit anti-SH3GL2 Antibody (A05430-2) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
Click image to see more details
Figure 5. IHC analysis of SH3GL2 using anti-SH3GL2 antibody (A05430-2).
SH3GL2 was detected in a paraffin-embedded section of mouse brain tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml rabbit anti-SH3GL2 Antibody (A05430-2) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
Click image to see more details
Figure 6. IHC analysis of SH3GL2 using anti-SH3GL2 antibody (A05430-2).
SH3GL2 was detected in a paraffin-embedded section of rat brain tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml rabbit anti-SH3GL2 Antibody (A05430-2) overnight at 4°C. Biotinylated goat anti-rabbit IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
Click image to see more details
Figure 7. IF analysis of SH3GL2 using anti-SH3GL2 antibody (A05430-2).
SH3GL2 was detected in an immunocytochemical section of Hela cells. Enzyme antigen retrieval was performed using IHC enzyme antigen retrieval reagent (AR0022) for 15 mins. The cells were blocked with 10% goat serum. And then incubated with 5 μg/mL rabbit anti-SH3GL2 Antibody (A05430-2) overnight at 4°C. DyLight®488 Conjugated Goat Anti-Rabbit IgG (BA1127) was used as secondary antibody at 1:100 dilution and incubated for 30 minutes at 37°C. The section was counterstained with DAPI. Visualize using a fluorescence microscope and filter sets appropriate for the label used.
Click image to see more details
Figure 8. Flow Cytometry analysis of JK cells using anti-SH3GL2 antibody (A05430-2).
Overlay histogram showing JK cells stained with A05430-2 (Blue line). To facilitate intracellular staining, cells were fixed with 4% paraformaldehyde and permeabilized with permeabilization buffer. The cells were blocked with 10% normal goat serum. And then incubated with rabbit anti-SH3GL2 Antibody (A05430-2, 1 μg/1x106 cells) for 30 min at 20°C. DyLight®488 conjugated goat anti-rabbit IgG (BA1127, 5-10 μg/1x106 cells) was used as secondary antibody for 30 minutes at 20°C. Isotype control antibody (Green line) was rabbit IgG (1 μg/1x106) used under the same conditions. Unlabelled sample without incubation with primary antibody and secondary antibody (Red line) was used as a blank control.
Protein Target Info & Infographic
Gene/Protein Information For SH3GL2 (Source: Uniprot.org, NCBI)
Gene Name
SH3GL2
Full Name
Endophilin-A1
Weight
39411 MW
Superfamily
endophilin family
Alternative Names
POU domain, class 4, transcription factor 1 SH3GL2 CNSA2, EEN-B1, SH3D2A, SH3P4 SH3 domain containing GRB2 like 2, endophilin A1 endophilin-A1|Endophilin A1 BAR domain|SH3 domain protein 2A|SH3 domain-containing GRB2-like protein 2|SH3-domain GRB2-like 2|bA335L15.1 (SH3-domain GRB2-like 2)|endophilin-1
*If product is indicated to react with multiple species, protein info is based on the gene entry specified above in "Species".For more info on SH3GL2, check out the SH3GL2 Infographic
We have 30,000+ of these available, one for each gene! Check them out.
In this infographic, you will see the following information for SH3GL2: database IDs, superfamily, protein function, synonyms, molecular weight, chromosomal locations, tissues of expression, subcellular locations, post-translational modifications, and related diseases, research areas & pathways. If you want to see more information included, or would like to contribute to it and be acknowledged, please contact [email protected].
