Product Info Summary
| SKU: | A16917-1 |
|---|---|
| Size: | 100 µg/vial |
| Reactive Species: | Human |
| Host: | Rabbit |
| Application: | ELISA, Flow Cytometry, IF, ICC, WB |
Customers Who Bought This Also Bought
Product info
Product Name
Anti-PPM1N Antibody Picoband®
SKU/Catalog Number
A16917-1
Size
100 µg/vial
Form
Lyophilized
Description
Boster Bio Anti-PPM1N Antibody Picoband® catalog # A16917-1. Tested in ELISA, Flow Cytometry, IF, ICC, WB applications. This antibody reacts with Human. The brand Picoband indicates this is a premium antibody that guarantees superior quality, high affinity, and strong signals with minimal background in Western blot applications. Only our best-performing antibodies are designated as Picoband, ensuring unmatched performance.
Storage & Handling
At -20°C for one year from date of receipt. After reconstitution, at 4°C for one month. It can also be aliquotted and stored frozen at -20°C for six months. Avoid repeated freezing and thawing.
Cite This Product
Anti-PPM1N Antibody Picoband® (Boster Biological Technology, Pleasanton CA, USA, Catalog # A16917-1)
Host
Rabbit
Contents
Each vial contains 4 mg Trehalose, 0.9 mg NaCl, 0.2 mg Na2HPO4.
Clonality
Polyclonal
Isotype
Rabbit IgG
Immunogen
E.coli-derived human PPM1N recombinant protein (Position: R36-A430).
*Blocking peptide can be purchased. Costs vary based on immunogen length. Contact us for pricing.
Cross-reactivity
No cross-reactivity with other proteins.
Reactive Species
A16917-1 is reactive to PPM1N in Human
Reconstitution
Adding 0.2 ml of distilled water will yield a concentration of 500 µg/ml.
Observed Molecular Weight
45 kDa
Calculated molecular weight
24145 MW
Background of PPM1N
Predicted to enable metal ion binding activity and protein serine/threonine phosphatase activity. Predicted to be involved in negative regulation of I-kappaB kinase/NF-kappaB signaling and positive regulation of canonical Wnt signaling pathway. Predicted to be active in cytosol and nucleus.
Antibody Validation
Boster validates all antibodies on WB, IHC, ICC, Immunofluorescence, and ELISA with known positive control and negative samples to ensure specificity and high affinity, including thorough antibody incubations.
Application & Images
Applications
A16917-1 is guaranteed for ELISA, Flow Cytometry, IF, ICC, WB Boster Guarantee
Assay Dilutions Recommendation
The recommendations below provide a starting point for assay optimization. The actual working concentration varies and should be decided by the user.
Western blot, 0.25-0.5 μg/ml, Human
Immunocytochemistry/Immunofluorescence, 5 μg/ml, Human
Flow Cytometry (Fixed), 1-3 μg/1x1x106 cells, Human
ELISA, 0.1-0.5 μg/ml, -
Positive Control
WB: human RT4 whole cell, human HEL whole cell, human K562 whole cell, human A549 whole cell
ICC/IF: A549 cell
FCM: MCF-7 cell
Validation Images & Assay Conditions
Click image to see more details
Figure 1. Western blot analysis of PPM1N using anti-PPM1N antibody (A16917-1).
Electrophoresis was performed on a 5-20% SDS-PAGE gel at 70V (Stacking gel) / 90V (Resolving gel) for 2-3 hours. The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: human RT4 whole cell lysates,
Lane 2: human HEL whole cell lysates,
Lane 3: human K562 whole cell lysates,
Lane 4: human A549 whole cell lysates.
After electrophoresis, proteins were transferred to a nitrocellulose membrane at 150 mA for 50-90 minutes. Blocked the membrane with 5% non-fat milk/TBS for 1.5 hour at RT. The membrane was incubated with rabbit anti-PPM1N antigen affinity purified polyclonal antibody (Catalog # A16917-1) at 0.5 μg/mL overnight at 4°C, then washed with TBS-0.1%Tween 3 times with 5 minutes each and probed with a goat anti-rabbit IgG-HRP secondary antibody at a dilution of 1:5000 for 1.5 hour at RT. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1002) with Tanon 5200 system. A specific band was detected for PPM1N at approximately 45 kDa. The expected band size for PPM1N is at 46 kDa.
Click image to see more details
Figure 2. IF analysis of PPM1N using anti-PPM1N antibody (A16917-1).
PPM1N was detected in an immunocytochemical section of A549 cells. Enzyme antigen retrieval was performed using IHC enzyme antigen retrieval reagent (AR0022) for 15 mins. The cells were blocked with 10% goat serum. And then incubated with 5 μg/mL rabbit anti-PPM1N Antibody (A16917-1) overnight at 4°C. DyLight®594 Conjugated Goat Anti-Rabbit IgG (BA1142) was used as secondary antibody at 1:500 dilution and incubated for 30 minutes at 37°C. The section was counterstained with DAPI. Visualize using a fluorescence microscope and filter sets appropriate for the label used.
Click image to see more details
Figure 3. Flow Cytometry analysis of MCF-7 cells using anti-PPM1N antibody (A16917-1).
Overlay histogram showing MCF-7 cells stained with A16917-1 (Blue line). To facilitate intracellular staining, cells were fixed with 4% paraformaldehyde and permeabilized with permeabilization buffer. The cells were blocked with 10% normal goat serum. And then incubated with rabbit anti-PPM1N Antibody (A16917-1, 1 μg/1x106 cells) for 30 min at 20°C. DyLight®488 conjugated goat anti-rabbit IgG (BA1127, 5-10 μg/1x106 cells) was used as secondary antibody for 30 minutes at 20°C. Isotype control antibody (Green line) was rabbit IgG (1 μg/1x106) used under the same conditions. Unlabelled sample (Red line) was also used as a control.
Protein Target Info & Infographic
Gene/Protein Information For PPM1N (Source: Uniprot.org, NCBI)
Gene Name
PPM1N
Full Name
Probable protein phosphatase 1N
Weight
24145 MW
Superfamily
PP2C family
Alternative Names
Kelch repeat and BTB domain-containing protein 2; BTB and kelch domain-containing protein 1; KBTBD2; BKLHD1; KIAA1489 PPM1N protein phosphatase, Mg2+/Mn2+ dependent 1N (putative) probable protein phosphatase 1N
*If product is indicated to react with multiple species, protein info is based on the gene entry specified above in "Species".For more info on PPM1N, check out the PPM1N Infographic
We have 30,000+ of these available, one for each gene! Check them out.
In this infographic, you will see the following information for PPM1N: database IDs, superfamily, protein function, synonyms, molecular weight, chromosomal locations, tissues of expression, subcellular locations, post-translational modifications, and related diseases, research areas & pathways. If you want to see more information included, or would like to contribute to it and be acknowledged, please contact [email protected].
