Product Info Summary
| SKU: | A11007-1 |
|---|---|
| Size: | 100 μg/vial |
| Reactive Species: | Human, Mouse, Rat |
| Host: | Rabbit |
| Application: | ELISA, Flow Cytometry, WB |
Customers Who Bought This Also Bought
Product info
Product Name
Anti-ERGIC1 Antibody Picoband®
SKU/Catalog Number
A11007-1
Size
100 μg/vial
Form
Lyophilized
Description
Boster Bio Anti-ERGIC1 Antibody Picoband® catalog # A11007-1. Tested in ELISA, Flow Cytometry, WB applications. This antibody reacts with Human, Mouse, Rat. The brand Picoband indicates this is a premium antibody that guarantees superior quality, high affinity, and strong signals with minimal background in Western blot applications. Only our best-performing antibodies are designated as Picoband, ensuring unmatched performance.
Storage & Handling
At -20°C for one year from date of receipt. After reconstitution, at 4°C for one month. It can also be aliquotted and stored frozen at -20°C for six months. Avoid repeated freezing and thawing.
Cite This Product
Anti-ERGIC1 Antibody Picoband® (Boster Biological Technology, Pleasanton CA, USA, Catalog # A11007-1)
Host
Rabbit
Contents
Each vial contains 4 mg Trehalose, 0.9 mg NaCl, 0.2 mg Na2HPO4.
Clonality
Polyclonal
Isotype
Rabbit IgG
Immunogen
E.coli-derived human ERGIC1 recombinant protein (Position: S42-H290).
*Blocking peptide can be purchased. Costs vary based on immunogen length. Contact us for pricing.
Cross-reactivity
No cross-reactivity with other proteins.
Reactive Species
A11007-1 is reactive to ERGIC1 in Human, Mouse, Rat
Reconstitution
Adding 0.2 ml of distilled water will yield a concentration of 500 μg/ml.
Observed Molecular Weight
35 kDa
Calculated molecular weight
32.592kDa
Background of ERGIC1
This gene encodes a cycling membrane protein which is an endoplasmic reticulum-golgi intermediate compartment (ERGIC) protein which interacts with other members of this protein family to increase their turnover.
Antibody Validation
Boster validates all antibodies on WB, IHC, ICC, Immunofluorescence, and ELISA with known positive control and negative samples to ensure specificity and high affinity, including thorough antibody incubations.
Application & Images
Applications
A11007-1 is guaranteed for ELISA, Flow Cytometry, WB Boster Guarantee
Assay Dilutions Recommendation
The recommendations below provide a starting point for assay optimization. The actual working concentration varies and should be decided by the user.
Western blot, 0.25-0.5 μg/ml, Human, Mouse, Rat
Flow Cytometry (Fixed), 1-3 μg/1x106 cells, Human
ELISA, 0.1-0.5 μg/ml, -
Positive Control
WB: human HepG2 whole cell, human U-87MG whole cell, rat brain tissue, rat liver tissue, rat RH35 whole cell, mouse brain tissue, mouse liver tissue, mouse NIH/3T3 whole cell
FCM: MCF-7 cell, U87 cell
Validation Images & Assay Conditions
Click image to see more details
Figure 1. Western blot analysis of ERGIC1 using anti-ERGIC1 antibody (A11007-1).
Electrophoresis was performed on a 5-20% SDS-PAGE gel at 70V (Stacking gel) / 90V (Resolving gel) for 2-3 hours. The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: human HepG2 whole cell lysates,
Lane 2: human U-87MG whole cell lysates,
Lane 3: rat brain tissue lysates,
Lane 4: rat liver tissue lysates,
Lane 5: rat RH35 whole cell lysates,
Lane 6: mouse brain tissue lysates,
Lane 7: mouse liver tissue lysates,
Lane 8: mouse NIH/3T3 whole cell lysates.
After electrophoresis, proteins were transferred to a nitrocellulose membrane at 150 mA for 50-90 minutes. Blocked the membrane with 5% non-fat milk/TBS for 1.5 hour at RT. The membrane was incubated with rabbit anti-ERGIC1 antigen affinity purified polyclonal antibody (Catalog # A11007-1) at 0.5 μg/mL overnight at 4°C, then washed with TBS-0.1%Tween 3 times with 5 minutes each and probed with a goat anti-rabbit IgG-HRP secondary antibody at a dilution of 1:5000 for 1.5 hour at RT. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1002) with Tanon 5200 system. A specific band was detected for ERGIC1 at approximately 35 kDa. The expected band size for ERGIC1 is at 33 kDa.
Click image to see more details
Figure 2. Flow Cytometry analysis of MCF-7 cells using anti-ERGIC1 antibody (A11007-1).
Overlay histogram showing MCF-7 cells stained with A11007-1 (Blue line). To facilitate intracellular staining, cells were fixed with 4% paraformaldehyde and permeabilized with permeabilization buffer. The cells were blocked with 10% normal goat serum. And then incubated with rabbit anti-ERGIC1 Antibody (A11007-1, 1 μg/1x106 cells) for 30 min at 20°C. DyLight®488 conjugated goat anti-rabbit IgG (BA1127, 5-10 μg/1x106 cells) was used as secondary antibody for 30 minutes at 20°C. Isotype control antibody (Green line) was rabbit IgG (1 μg/1x106) used under the same conditions. Unlabelled sample without incubation with primary antibody and secondary antibody (Red line) was used as a blank control.
Click image to see more details
Figure 3. Flow Cytometry analysis of U87 cells using anti-ERGIC1 antibody (A11007-1).
Overlay histogram showing U87 cells stained with A11007-1 (Blue line). To facilitate intracellular staining, cells were fixed with 4% paraformaldehyde and permeabilized with permeabilization buffer. The cells were blocked with 10% normal goat serum. And then incubated with rabbit anti-ERGIC1 Antibody (A11007-1, 1 μg/1x106 cells) for 30 min at 20°C. DyLight®488 conjugated goat anti-rabbit IgG (BA1127, 5-10 μg/1x106 cells) was used as secondary antibody for 30 minutes at 20°C. Isotype control antibody (Green line) was rabbit IgG (1 μg/1x106) used under the same conditions. Unlabelled sample without incubation with primary antibody and secondary antibody (Red line) was used as a blank control.
Protein Target Info & Infographic
Gene/Protein Information For ERGIC1 (Source: Uniprot.org, NCBI)
Gene Name
ERGIC1
Full Name
Endoplasmic reticulum-Golgi intermediate compartment protein 1
Weight
32.592kDa
Superfamily
ERGIC family
Alternative Names
Interleukin-17B; IL-17B; Cytokine CX1; Cytokine-like protein ZCYTO7; Neuronal interleukin-17-related factor; Il17b; Nirf, Zcyto7 ERGIC1 AMC2, AMCN, ERGIC-32, ERGIC32, NET24 endoplasmic reticulum-golgi intermediate compartment 1 endoplasmic reticulum-Golgi intermediate compartment protein 1|ER-Golgi intermediate compartment 32 kDa protein|endoplasmic reticulum-golgi intermediate compartment (ERGIC) 1|endoplasmic reticulum-golgi intermediate compartment 32 kDa protein
*If product is indicated to react with multiple species, protein info is based on the gene entry specified above in "Species".For more info on ERGIC1, check out the ERGIC1 Infographic
We have 30,000+ of these available, one for each gene! Check them out.
In this infographic, you will see the following information for ERGIC1: database IDs, superfamily, protein function, synonyms, molecular weight, chromosomal locations, tissues of expression, subcellular locations, post-translational modifications, and related diseases, research areas & pathways. If you want to see more information included, or would like to contribute to it and be acknowledged, please contact [email protected].
