Product Info Summary
| SKU: | M00548-2 |
|---|---|
| Size: | 100 μg/vial |
| Reactive Species: | Human, Mouse, Rat |
| Host: | Mouse |
| Application: | IF, IHC, ICC, WB |
Customers Who Bought This Also Bought
Product info
Product Name
Anti-AREB6/ZEB1 Antibody Picoband® (monoclonal, 8B12D7)
SKU/Catalog Number
M00548-2
Size
100 μg/vial
Form
Lyophilized
Description
Boster Bio Anti-AREB6/ZEB1 Antibody Picoband® (monoclonal, 8B12D7) catalog # M00548-2. Tested in IF, IHC, ICC, WB applications. This antibody reacts with Human, Mouse, Rat. The brand Picoband indicates this is a premium antibody that guarantees superior quality, high affinity, and strong signals with minimal background in Western blot applications. Only our best-performing antibodies are designated as Picoband, ensuring unmatched performance.
Storage & Handling
At -20°C for one year from date of receipt. After reconstitution, at 4°C for one month. It can also be aliquotted and stored frozen at -20°C for six months. Avoid repeated freezing and thawing.
Cite This Product
Anti-AREB6/ZEB1 Antibody Picoband® (monoclonal, 8B12D7) (Boster Biological Technology, Pleasanton CA, USA, Catalog # M00548-2)
Host
Mouse
Contents
Each vial contains 4 mg Trehalose, 0.9 mg NaCl and 0.2 mg Na2HPO4.
Clonality
Monoclonal
Clone Number
8B12D7
Isotype
Mouse IgG2b
Immunogen
A synthetic peptide corresponding to a sequence in the middle region of human AREB6/ZEB1.
*Blocking peptide can be purchased. Costs vary based on immunogen length. Contact us for pricing.
Cross-reactivity
No cross-reactivity with other proteins.
Reactive Species
M00548-2 is reactive to ZEB1 in Human, Mouse, Rat
Reconstitution
Adding 0.2 ml of distilled water will yield a concentration of 500 μg/ml.
Observed Molecular Weight
200 kDa
Calculated molecular weight
56.381kDa
Background of ZEB1
ZEB1 (Zinc Finger E Box-Binding Homeobox 1), also called TCF8, NIL2A or DELTA-EF1, is a protein that in humans is encoded by the ZEB1 gene. Fluorescence in situ hybridization localized the ZEB1 gene to chromosome 10p11.2. Krafchak et al. (2005) demonstrated a complex (core plus secondary) binding site for TCF8 in the promoter of the COL4A3 gene, mutant in Alport syndrome and which encodes collagen type IV alpha-3. They detected expression of TCF8 in cornea. Nishimura et al. (2006) found that delta-Ef1 was upregulated during differentiation in a mouse smooth muscle cell (SMC) line.
Antibody Validation
Boster validates all antibodies on WB, IHC, ICC, Immunofluorescence, and ELISA with known positive control and negative samples to ensure specificity and high affinity, including thorough antibody incubations.
Application & Images
Applications
M00548-2 is guaranteed for IF, IHC, ICC, WB Boster Guarantee
Assay Dilutions Recommendation
The recommendations below provide a starting point for assay optimization. The actual working concentration varies and should be decided by the user.
Western blot, 0.25-0.5 μg/ml, Human, Mouse, Rat
Immunohistochemistry(Paraffin-embedded Section), 2-5 μg/ml, Human, Mouse, Rat
Immunocytochemistry/Immunofluorescence, 5 μg/ml, Human
Immunofluorescence, 5 μg/ml, Human
Positive Control
WB: human U87 whole cell, rat brain tissue, mouse brain tissue, mouse lung tissue
IHC: human glioblastoma tissue, human thyroid cancer tissue, human breast cancer tissue, human colorectal adenocarcinoma tissue, human laryngeal squamous cell carcinoma tissue, human lung adenocarcinoma tissue, human testicular germ cell tumor tissue, mouse brain tissue, rat brain tissue
ICC/IF: U87 cell
IF: human glioma tissue
Validation Images & Assay Conditions
Click image to see more details
Figure 1. Western blot analysis of AREB6/ZEB1 using anti-AREB6/ZEB1 antibody (M00548-2).
Electrophoresis was performed on a 5-20% SDS-PAGE gel at 70V (Stacking gel) / 90V (Resolving gel) for 2-3 hours. The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: human U87 whole cell lysates,
Lane 2: rat brain tissue lysates,
Lane 3: mouse brain tissue lysates,
Lane 4: mouse lung tissue lysates.
After electrophoresis, proteins were transferred to a nitrocellulose membrane at 150 mA for 50-90 minutes. Blocked the membrane with 5% non-fat milk/TBS for 1.5 hour at RT. The membrane was incubated with mouse anti-AREB6/ZEB1 antigen affinity purified monoclonal antibody (Catalog # M00548-2) at 0.5 μg/mL overnight at 4°C, then washed with TBS-0.1%Tween 3 times with 5 minutes each and probed with a goat anti-mouse IgG-HRP secondary antibody at a dilution of 1:10000 for 1.5 hour at RT. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1001) with Tanon 5200 system. A specific band was detected for AREB6/ZEB1 at approximately 200 kDa. The expected band size for AREB6/ZEB1 is at 124 kDa.
Click image to see more details
Figure 2. IHC analysis of AREB6/ZEB1 using anti-AREB6/ZEB1 antibody (M00548-2).
AREB6/ZEB1 was detected in a paraffin-embedded section of human glioblastoma tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml mouse anti-AREB6/ZEB1 Antibody (M00548-2) overnight at 4°C. Peroxidase Conjugated Goat Anti-mouse IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using HRP Conjugated Mouse IgG Super Vision Assay Kit (Catalog # SV0001) with DAB as the chromogen.
Click image to see more details
Figure 3. IHC analysis of AREB6/ZEB1 using anti-AREB6/ZEB1 antibody (M00548-2).
AREB6/ZEB1 was detected in a paraffin-embedded section of human thyroid cancer tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml mouse anti-AREB6/ZEB1 Antibody (M00548-2) overnight at 4°C. Peroxidase Conjugated Goat Anti-mouse IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using HRP Conjugated Mouse IgG Super Vision Assay Kit (Catalog # SV0001) with DAB as the chromogen.
Click image to see more details
Figure 4. IHC analysis of AREB6/ZEB1 using anti-AREB6/ZEB1 antibody (M00548-2).
AREB6/ZEB1 was detected in a paraffin-embedded section of human breast cancer tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml mouse anti-AREB6/ZEB1 Antibody (M00548-2) overnight at 4°C. Peroxidase Conjugated Goat Anti-mouse IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using HRP Conjugated Mouse IgG Super Vision Assay Kit (Catalog # SV0001) with DAB as the chromogen.
Click image to see more details
Figure 5. IHC analysis of AREB6/ZEB1 using anti-AREB6/ZEB1 antibody (M00548-2).
AREB6/ZEB1 was detected in a paraffin-embedded section of human colorectal adenocarcinoma tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml mouse anti-AREB6/ZEB1 Antibody (M00548-2) overnight at 4°C. Peroxidase Conjugated Goat Anti-mouse IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using HRP Conjugated Mouse IgG Super Vision Assay Kit (Catalog # SV0001) with DAB as the chromogen.
Click image to see more details
Figure 6. IHC analysis of AREB6/ZEB1 using anti-AREB6/ZEB1 antibody (M00548-2).
AREB6/ZEB1 was detected in a paraffin-embedded section of human laryngeal squamous cell carcinoma tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml mouse anti-AREB6/ZEB1 Antibody (M00548-2) overnight at 4°C. Peroxidase Conjugated Goat Anti-mouse IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using HRP Conjugated Mouse IgG Super Vision Assay Kit (Catalog # SV0001) with DAB as the chromogen.
Click image to see more details
Figure 7. IHC analysis of AREB6/ZEB1 using anti-AREB6/ZEB1 antibody (M00548-2).
AREB6/ZEB1 was detected in a paraffin-embedded section of human lung adenocarcinoma tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml mouse anti-AREB6/ZEB1 Antibody (M00548-2) overnight at 4°C. Peroxidase Conjugated Goat Anti-mouse IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using HRP Conjugated Mouse IgG Super Vision Assay Kit (Catalog # SV0001) with DAB as the chromogen.
Click image to see more details
Figure 8. IHC analysis of AREB6/ZEB1 using anti-AREB6/ZEB1 antibody (M00548-2).
AREB6/ZEB1 was detected in a paraffin-embedded section of human testicular germ cell tumor tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml mouse anti-AREB6/ZEB1 Antibody (M00548-2) overnight at 4°C. Peroxidase Conjugated Goat Anti-mouse IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using HRP Conjugated Mouse IgG Super Vision Assay Kit (Catalog # SV0001) with DAB as the chromogen.
Click image to see more details
Figure 9. IHC analysis of AREB6/ZEB1 using anti-AREB6/ZEB1 antibody (M00548-2).
AREB6/ZEB1 was detected in a paraffin-embedded section of mouse brain tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml mouse anti-AREB6/ZEB1 Antibody (M00548-2) overnight at 4°C. Peroxidase Conjugated Goat Anti-mouse IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using HRP Conjugated Mouse IgG Super Vision Assay Kit (Catalog # SV0001) with DAB as the chromogen.
Click image to see more details
Figure 10. IHC analysis of AREB6/ZEB1 using anti-AREB6/ZEB1 antibody (M00548-2).
AREB6/ZEB1 was detected in a paraffin-embedded section of rat brain tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 2 μg/ml mouse anti-AREB6/ZEB1 Antibody (M00548-2) overnight at 4°C. Peroxidase Conjugated Goat Anti-mouse IgG was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using HRP Conjugated Mouse IgG Super Vision Assay Kit (Catalog # SV0001) with DAB as the chromogen.
Click image to see more details
Figure 11. IF analysis of AREB6/ZEB1 using anti-AREB6/ZEB1 antibody (M00548-2).
AREB6/ZEB1 was detected in a paraffin-embedded section of human glioma tissue. Heat mediated antigen retrieval was performed in EDTA buffer (pH 8.0, epitope retrieval solution). The tissue section was blocked with 10% goat serum. The tissue section was then incubated with 5 μg/mL mouse anti-AREB6/ZEB1 Antibody (M00548-2) overnight at 4°C. Biotin conjugated goat anti-mouse IgG (BA1001) was used as secondary antibody and incubated for 30 minutes at 37°C. The tissue section was developed using DyLight®550 Conjugated Avidin (BA1134). Visualize using a fluorescence microscope and filter sets appropriate for the label used.
Click image to see more details
Figure 12. IF analysis of AREB6/ZEB1 using anti-AREB6/ZEB1 antibody (M00548-2).
AREB6/ZEB1 was detected in an immunocytochemical section of U87 cells. Enzyme antigen retrieval was performed using IHC enzyme antigen retrieval reagent (AR0022) for 15 mins. The cells were blocked with 10% goat serum. And then incubated with 5 μg/mL mouse anti-AREB6/ZEB1 Antibody (M00548-2) overnight at 4°C. DyLight®550 Conjugated Goat Anti-Mouse IgG (BA1133) was used as secondary antibody at 1:500 dilution and incubated for 30 minutes at 37°C. Visualize using a fluorescence microscope and filter sets appropriate for the label used.
Protein Target Info & Infographic
Gene/Protein Information For ZEB1 (Source: Uniprot.org, NCBI)
Gene Name
ZEB1
Full Name
Zinc finger E-box-binding homeobox 1
Weight
56.381kDa
Superfamily
delta-EF1/ZFH-1 C2H2-type zinc-finger family
Alternative Names
Aldehyde dehydrogenase, mitochondrial; ALDH class 2; ALDH-E2; ALDHI; ALDH2; ALDM ZEB1 AREB6, BZP, DELTAEF1, FECD6, NIL2A, PPCD3, TCF8, ZFHEP, ZFHX1A zinc finger E-box binding homeobox 1 zinc finger E-box-binding homeobox 1|delta-crystallin enhancer binding factor 1|negative regulator of IL2|posterior polymorphous corneal dystrophy 3|transcription factor 8 (represses interleukin 2 expression)|zinc finger homeodomain enhancer-binding protein
*If product is indicated to react with multiple species, protein info is based on the gene entry specified above in "Species".For more info on ZEB1, check out the ZEB1 Infographic
We have 30,000+ of these available, one for each gene! Check them out.
In this infographic, you will see the following information for ZEB1: database IDs, superfamily, protein function, synonyms, molecular weight, chromosomal locations, tissues of expression, subcellular locations, post-translational modifications, and related diseases, research areas & pathways. If you want to see more information included, or would like to contribute to it and be acknowledged, please contact [email protected].
